The ROPE-MOP OIL SKIMMER is mainly composed of power station, extruder, hydraulic oil pipe, oil pipeline and the recovery rope for adhering to oil spills. It can carry out the recovery operations for oil spills of different viscosities under severe conditions. It is widely used in the recovery of oil spills from oceans, rivers, lakes, pools, industrial wastewater and etc.
The power station operates with the hydraulic oil pump and oil delivery pump driven by diesel engine or motor. The main unit is composed of the extruding roller unit, oil collecting channel, frame, hydraulic oil hose, oil pipeline and other parts. The main unit is hung at the ship’s side above the water (the desktop skimmer is set on the shore) while the power station is located on the boat or shore.?
The oil recovery rope is made of the lipophilic polypropylene fibers with excellence lipophilicity. After being stained with oil, it still has oil absorption capacity. The specific gravity of the recovery rope is approximately 0.9. It can float on waters and move with waves and keep in touch with oil spills.?
The operating temperature for the recovery rope is between -35℃ and 70℃. It can recover oil spills under the ice layer.
In the recovery process, it can move zigzag to absorb oils between the object and floating waste without the affection of debris. It can also recover oil spills from a narrow space such as deep pit.?
The trolley and hanging extruders are available for selection. The trolley skimmer is fixed on shore or boat, using the floating guide pulley and the long recovery rope to recover the oil spills on the water surface. The hanging recovery rope is hanging on the water surface where the oil spills are located. Its operation is easy and simple. It is adaptable to bad conditions.?
|
?Model ? ? ? ? ? ? ? ? ??? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Parameter?? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? |
SS-5 ? ? ? ? ? ? ? ? |
SS-10 ? ? ? ? ? ? ? ? |
SS-20 ? ? ? ? ? ? ? ? |
SS-30 ? ? ? ? ? ? ? ? |
Max. Recovery Rate??(m3/h) ? ? ? ? ? ? ? ? |
5 ? ? ? ? ? ? ? ? |
10 ? ? ? ? ? ? ? ? |
20 ? ? ? ? ? ? ? ? |
30 ? ? ? ? ? ? ? ? |
Diameter of the Rope?（mm） ? ? ? ? ? ? ? ? |
∮300 ? ? ? ? ? ? ? ? |
∮300 ? ? ? ? ? ? ? ? |
∮300 ? ? ? ? ? ? ? ? |
∮300 ? ? ? ? ? ? ? ? |
Length of the Rope ? ? ? ? ? ? ? ? |
7 meters or any length can be customized ? ? ? ? ? ? ? ? |
|||
Quantity of the Rope ? ? ? ? ? ? ? ? |
1piece ? ? ? ? ? ? ? ? |
2pieces ? ? ? ? ? ? ? ? |
3pieces ? ? ? ? ? ? ? ? |
4pieces ? ? ? ? ? ? ? ? |
Driving Power(KW)?(Diesel Engine or Explosion Proof Motor) ? ? ? ? ? ? ? ? |
6.3/4 ? ? ? ? ? ? ? ? |
6.3/4 ? ? ? ? ? ? ? ? |
6.3/ 7.5 ? ? ? ? ? ? ? ? |
14.5/11 ? ? ? ? ? ? ? ? |
Type ? ? ? ? ? ? ? ? |
Hanging ? ? ? ? ? ? ? ? |
Hanging ? ? ? ? ? ? ? ? |
Hanging ? ? ? ? ? ? ? ? |
Handing ? ? ? ? ? ? ? ? |
