PVC OIL FENCE BOOM is a simple, economic and effective oil containment boom, which is widely used in seaports, rivers, lakes, ponds, oil-water separation tanks and other occasions.
The oil fence boom is made of high strength fabric coated with bright orange PVC, which has the characteristics of oil resistance, seawater corrosion resistance and UV radiation resistance. The solid float in the unique shape makes it easier to store. There is a force-withstanding element each in the upper and lower parts of the boom body to ensure the strength. Elastic supporting bar is set between the solid floats to keep the oil fence straight and ensure the effective draft.
The deployment and retrieval of the PVC oil fence boom is very simple. The oil fence boom can be equipped with hydraulic drive reel frame or hanging storage rack.?
|
?Model ? ? ? ? ? ? ? ? Parameter?? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? |
SWL600 ? ? ? ? ? ? ? ? |
SWL 800 ? ? ? ? ? ? ? ? |
SWL 1000 ? ? ? ? ? ? ? ? |
SWL 1100 ? ? ? ? ? ? ? ? |
Overall Height?（mm） ? ? ? ? ? ? ? ? |
600 ? ? ? ? ? ? ? ? |
800 ? ? ? ? ? ? ? ? |
1000 ? ? ? ? ? ? ? ? |
1100 ? ? ? ? ? ? ? ? |
Freeboard?（mm） ? ? ? ? ? ? ? ? |
200 ? ? ? ? ? ? ? ? |
300 ? ? ? ? ? ? ? ? |
350 ? ? ? ? ? ? ? ? |
400 ? ? ? ? ? ? ? ? |
Draft?（mm） ? ? ? ? ? ? ? ? |
350 ? ? ? ? ? ? ? ? |
500 ? ? ? ? ? ? ? ? |
600 ? ? ? ? ? ? ? ? |
700 ? ? ? ? ? ? ? ? |
Length per Section?（m） ? ? ? ? ? ? ? ? |
10，?20 ? ? ? ? ? ? ? ? |
|||
Max. Working Tensile Strength?（KN） ? ? ? ? ? ? ? ? |
20 ? ? ? ? ? ? ? ? |
25 ? ? ? ? ? ? ? ? |
30 ? ? ? ? ? ? ? ? |
35 ? ? ? ? ? ? ? ? |
Max. Resistance to Wave Height?(m) ? ? ? ? ? ? ? ? |
0.2 ? ? ? ? ? ? ? ? |
0.3 ? ? ? ? ? ? ? ? |
0.4 ? ? ? ? ? ? ? ? |
0.5 ? ? ? ? ? ? ? ? |
Max. Resistance to Wind Speed?(m/s) ? ? ? ? ? ? ? ? |
0.2 ? ? ? ? ? ? ? ? |
0.3 ? ? ? ? ? ? ? ? |
0.4 ? ? ? ? ? ? ? ? |
0.5 ? ? ? ? ? ? ? ? |
Max. Resistance to Current Speed(Kn) ? ? ? ? ? ? ? ? |
0.2 ? ? ? ? ? ? ? ? |
0.3 ? ? ? ? ? ? ? ? |
0.4 ? ? ? ? ? ? ? ? |
0.5 ? ? ? ? ? ? ? ? |
Ballast ? ? ? ? ? ? ? ? |
Block or Ballast Chain ? ? ? ? ? ? ? ? |
|||
